Dust Boot v3 for CNC Dust Collection - Pixels to Prototype - Customizable, Fits most CNCs!

Dust Boot v3 for CNC Dust Collection - Pixels to Prototype - Customizable, Fits most CNCs!

Regular price $114.99 USD
Regular price Sale price $114.99 USD
Sale Sold out
Tax included. Shipping calculated at checkout.

I spent hours and hours testing and trying many dust boots on several CNCs that I have had over the years. I had some that the brush piece would dislodge and cause ruined jobs. I have had others that made it so frustrating to make tool changes that I tried to avoid them at all costs! Well after all this trial and error, I have come up with the design you see here -- the Pixels to Prototype dust boot. This dust boot is designed from the ground up in Fusion360 making it very easy to adjust and adapt for many different machines, spindles, and setups. If you have a custom need, please to not hesitate to reach out!

Features:
- Screw clamp for attaching firmly and quickly to the spindle.
- 3" nylon brush with Magnet attachment. This also features tabs to prevent the brush dislodging in the middle of a job. Additional brushes are available in the store. Brushes are interchangeable and can be easily cut to specific lengths with scissors. Purchase a 2nd/spare brush for shorter tooling!
- Brush has slit for easy removal to perform tool changes.
- Brush is custom made in the USA for this boot!
- Quick Connect Hose Adapter - easily remove hose from the boot for tool changes or machine work!
- We have several colors available -- if you have a specific color preference, please let us know and we will do our best to accommodate! The default boot color is black.

*** Please note that the Boot Brush may need to be trimmed for your specific setup. The 3" brush is long enough to cover most tools, but typically needs to be cut back for small tools. Please use caution when first setting up the boot and consider buying a second brush so that you can have short and long options.

We offer a huge range of boots for MANY applications but with the sheer number of CNCs out there and the different configurations - please do not hesitate to contact us with any questions or concerns. We have made many custom boots for DIY Machines, Stepcraft, EZ Router, and Industrial CNC Machines.

Spindle Size Details:
- Makita/Carbide - 65mm diameter - 65mm Boot - Popular on Onefinity, XCarve, Shapeoko, Open Builds, and DIY CNCs
- 70mm - DeWalt DWP611 Router. Has slot for collet lock
- 76mm - Old Phantom CNC SCV44 Machine Spindle
- 2hp / 1.5kW / 2.5kW / 80mm Spindle - 80mm Boot
- 85mm - Phantom CNC S-Series 4x8 Machine
- 85mm - Phantom CNC SCV/SCA Machines (After 3/12/2024)
- 100mm - Spindle

Adapters:
***DEFAULT IS A 4IN DUST COLLECTOR HOSE ADAPTER. PLEASE PUT IN THE NOTES IF YOU WOULD LIKE A DIFFERENT SIZE!
- 1.25"OD Adapter - Outside is tapered from 1.21" (30.75mm) to 1.25" (31.75mm) for connection. Designed for the hose to go over the end and be clamped via ziptie. This is designed for a 1.25" plastic ShopVac-type hose.
- 1.5"ID Adapter - Adapter OD fits the Rockler Dust Collection FlexiPort 1.5" ID
- 1.75"OD Adapter - Adapter ID is Tapered from (45.45mm) to (44.59mm). OD of adapter is (52.45mm). Designed for the hose to fit inside the adapter. This fits hoses just like the XCarve Dust Shoe and was made as a direct replacement for an Xcarve shoe.
- 2.25"OD Adapter - Adapter ID is Tapered from (58.15mm) to (57.25mm). OD of adapter is (65.15mm). Designed for the hose to fit inside the adapter. This is designed for a 2.25" plastic ShopVac-type hose.
- 2.5"OD Adapter - Adapter ID is (52.325mm). OD of adapter is (60.325mm). Designed for a Dust Collection 2.5" Hose to be clamped on the outside of the adapter.
- 3"OD Adapter - Adapter for 3" Dust Collector Hose
- 4"OD Adapter - Adapter for 4" Dust Collector Hose
- Custom Adapter - Can be made to any size!

With the sheer number of CNCs out there and the different configurations - please do not hesitate to contact me with any questions or concerns.
